STAMOS combination welding machine with 180 A WIG and 50 A cut as well as MMA

• For welding and cutting: WIG, plasma, MMA
• Powerful 180 A welding current for WIG welding, 100% duty cycle from below 139 A
• Cutting capacity up to 16 mm at 50 A with plasma cutting
• Effective electrode welding with Hot Start
• Mobile thanks to the carrying handle

Can a welder also cut metals? The STAMOS Welding Group says: “Yes!” – with the 3-in-1 combination welding device S-MULTI 51. The high-quality device from the STAMOS Germany series is a real all-rounder that reliably welds with the WIG and MMA welding methods and Powerfully cuts metals with a plasma torch. Thanks to the tried-and-tested MOSFET inverter and the high-frequency ignition for WIG and plasma, the mobile combination welding machine with carrying handle can handle any welding task with impressive results.

The 3-in-1 combination welding machine enables WIG welding with high performance values

If you need high-quality weld seams and want to weld self-melting metals such as steel, magnesium, copper, or titanium from 0.5 mm, then the WIG welding method of the combination welding machine is optimally adjusted to your work. The welding torch with a 4 m long hose package gives you the freedom of movement you need when welding. For inert gas welding, you can use tungsten electrodes with a diameter of 0.5 to 3.2 mm and thus meet a wide range of welding requirements.

For WIG welding, the welding current can be regulated from 10 to 180 A, so that you have a wide power spectrum at your disposal. With a welding current below 139 A, you can even weld with a 100% duty cycle and easily manage even longer welding distances. You can achieve optimal cooling of the weld seam with the adjustable gas post-flow time of 2.5 or 5 s.

Plasma cutting with the STAMOS combination welding device

The combination welder is equipped with a connection for a plasma cutter, through which the high-quality cutting torch PT-31 is reliably supplied with compressed air and electricity for cutting metal. A stable plasma arc is generated at 4.5 bar, which can reliably cut metals up to 16 mm. A maximum cutting current of 50 A is available for this purpose. At 39 amps or less, you can cut metals cleanly and reliably with 100% duty cycle.

The plasma cutter is equipped with a professional hose package that, thanks to its 4 m length, offers maximum freedom of movement when cutting metals. The compressed air supply can be perfectly adjusted via a pressure valve with a manometer, with which you can achieve high-quality kerfs with plasma cutting.

Even without gas, the combination welding machine offers precise performance values

If you want to weld without gas, then simply use the 3-in-1 combination welding device for electrode welding. The welding method is extremely flexible, can be used for numerous repair and maintenance jobs and offers high-quality welds right from the start thanks to Hot Start. The combination welding machine is equipped with a high-quality electrode holder for electrodes up to 4 mm, which, thanks to the 3.5 m cable, gives you the freedom of movement you need for welding.

Whether you want to cut metal or weld, with the 3-in-1 combination welding machine you have all the options – use them!

• Combination welding machine S-MULTI 51
• Electrode holder with cable (3.5 m)
• Plasma torch PT-31 with professional hose package (4 m)
• WIG torch with hose package (4 m)
• Ground cable with clamp (3.6 m)
• Air hose (3.7 m)
• Manometer
• Pressure valve
• 3 clamping sleeves (1.6 / 2 / 2.4 mm)
• Clamping sleeve holder
• 3 ceramic sleeves (4 / 5 / 6 mm)
• Burner cap long
• Burner cap short
• 2 nozzles and electrodes for plasma
• Ceramic caps and swirl rings for plasma
• Accessories bag
• Instruction manual
